Custom Wire Harness Assembly Design Guide: 5 Decisions That Impact Performance and Cost

Custom Wire Harness Assembly Design Guide, At Auctus Electro Assembly, we have spent over 60 years engineering wire harnesses for medical, industrial, aerospace, and commercial applications. We have seen designs that worked beautifully—and designs that created problems no one anticipated.

This guide walks you through five critical design decisions. Get them right, and you build a harness that delivers performance, reliability, and value. Get them wrong, and you inherit cost overruns, field failures, and production delays.

Decision 1: Conductor Selection — Stranding and Material

The conductor is the heart of your harness. It carries power or signal. Its construction determines flexibility, current capacity, and lifespan.

Stranding: Solid vs. Stranded

Solid conductors are a single wire. They are inexpensive and work well in stationary applications—inside a control cabinet, for example. But they fatigue and break under vibration or flexing.

Stranded conductors use multiple small wires twisted together. Higher strand counts mean greater flexibility. For applications involving motion robotic arms, cable carriers, vibrating equipment—high-strand conductors are essential.

Material: Copper vs. Alternatives

Copper is the standard. Excellent conductivity, reasonable cost, easy to terminate.

Tinned copper adds corrosion resistance—critical for marine or high-humidity environments.

Aluminum is lighter but requires larger gauges for equivalent current capacity. Termination requires special care to avoid galvanic corrosion.

Decision 2: Insulation and Jacket Materials — Protecting the Conductors

Insulation surrounds each conductor. The jacket protects the entire bundle. Together, they determine where your harness can survive.

Common Materials and Their Applications

Material	Key Properties	Best For
PVC	General purpose, flexible, cost-effective	Indoor commercial, consumer products
PUR	Tough, oil-resistant, abrasion-resistant	Industrial, factory floor, continuous flex
TPE	Rubber-like flexibility, good grip	Medical devices, test leads
Silicone	Extreme temperature range (-65°C to 200°C)	High-heat environments, cold flex
FEP/PFA	Chemical resistant, high temperature	Aerospace, medical, harsh chemicals

Critical Factors

Temperature range: A harness rated for -20°C to 60°C will fail in an industrial oven or freezer.

Chemical exposure: Cutting fluids, hydraulic oil, cleaning solvents—each attacks different materials.

UV resistance: Outdoor installations need UV-stabilized jackets.

Abrasion resistance: Harnesses dragged across floors need tough outer layers.

Decision 3: Connector Selection — The Interface Matters Most

The connector is where your harness meets the world. It is also the most common failure point.

Electrical Requirements

Pin count: Enough for current needs, with room for future expansion?

Current rating: Each contact must handle the required amperage.

Voltage rating: Insulation must withstand peak voltages.

Impedance: For signal cables, impedance matching prevents reflections.

Mechanical Requirements

Mating cycles: How many times will this connector be connected and disconnected?

Insertion force: High pin-count connectors require significant force—consider zero-insertion-force (ZIF) designs.

Locking mechanism: Vibration demands positive locking—threaded, bayonet, or latching.

Environmental Requirements

Ingress protection (IP rating): IP67 for occasional immersion, IP69K for high-pressure washdown.

Plating: Gold for low-voltage signals and corrosion resistance. Tin for cost-sensitive applications.

Decision 4: Shielding Strategy — Managing EMI

In electrically noisy environments, shielding is not optional.

Shield Types

Foil: 100% coverage, excellent for high-frequency noise. Poor flex life. Best for static installations.

Braid: 70-95% coverage, flexible and durable. Good for low-frequency protection.

Combination (foil + braid): Best of both worlds—high-frequency protection plus mechanical durability.

Termination Matters

A shield is only as good as its termination. A “pigtail” ground can become an antenna. 360-degree termination to a shielded connector backshell creates a true Faraday cage.

Design Impact: Inadequate shielding guarantees data corruption or erratic performance in industrial environments.

Decision 5: Strain Relief and Mechanical Protection

The junction between cable and connector is the most mechanically stressed point.

Strain Relief Methods

Molded strain relief: The jacket is overmolded to create a tapered, flexible transition. Best for high-flex applications.

Heat-shrink strain relief: Adhesive-lined heat shrink reinforces the transition. Good for field assemblies.

Mechanical clamps: The cable jacket is clamped to the connector backshell. Pull forces transfer to the clamp, not the terminations.

Additional Protection

Braided sleeving: Adds abrasion resistance for high-wear areas.

Convoluted tubing: Protects against crushing and abrasion.

Flexible conduit: Maximum protection for extreme environments.
